Diamond Dotted Insulation Paper for Transformers
Also known as: DDP Paper, Diamond Dotted Paper
Diamond dotted insulation paper uses a controlled diamond pattern of modified epoxy resin on electrical insulation paper. During the specified drying and heating process, the resin supports bonding between winding layers while leaving paths for oil penetration and gas release.
Dimensions, materials, tolerances and testing requirements are confirmed according to customer drawings and order specifications.
Key functions and options
- Supports interlayer and turn-to-turn insulation
- Diamond-dot resin pattern
- Promotes oil penetration and gas release
- Improves winding mechanical stability after curing
Typical applications
- Oil-immersed power transformer windings
- Interlayer insulation
- Turn-to-turn insulation
Quotation preparation
Information to include with your RFQ
- Base paper thickness
- Roll width and length
- Resin pattern or specification
- Quantity
For custom parts, a dimensioned drawing is the most reliable starting point. Drawings can be emailed to sales@boreviax.com.
Product guidance
Diamond dotted insulation paper for winding bonding and interlayer insulation
Diamond dotted paper, commonly abbreviated as DDP, is selected where electrical insulation paper also needs a controlled bonding function. The paper base, resin pattern, dimensions and curing process must be matched to the winding design and manufacturing procedure.
Typical purchasing considerations
- Paper grade and nominal thickness
- Roll width, roll length and core requirement
- Single-sided or double-sided coating configuration
- Resin pattern or project-specific requirement
- Packing, moisture protection and storage instructions
Project support
- Specification and application clarification
- Sample or documentation review where required
- Order and production follow-up
- Export packing and documentation coordination
- After-sales investigation and replacement coordination
Diamond dotted paper FAQs
What information is needed for a DDP quotation?
Provide the paper grade, thickness, roll dimensions, coating configuration, quantity, applicable standard, packing requirement and delivery destination.
Is DDP the same as plain transformer insulation paper?
No. DDP includes a patterned resin coating that supports bonding during the specified heating process; plain insulating paper does not provide the same coated bonding function.
